    Waterproof 310W 36V Monocrystalline Solar Panel , Thin Solar Panels With White Aluminum

    Ask Lasest Price
    Brand Name : SHINE OR OEM
    Model Number : SN-M300
    Certification : CE, LVD, TUV, IEC, ROSH, SGS
    Price : negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 20000 pcs per month
    Delivery Time : 15 days
    • Product Details
    • Company Profile

    Waterproof 310W 36V Monocrystalline Solar Panel , Thin Solar Panels With White Aluminum


    Foldable 310Watt 36V Monocrystalline Solar Panel with white Aluminum for power station

    Specification of this monocrystalline solar panel

    100Watt Monocrystalline Solar Panel
    Mechanical Characteristics
    Characteristics
    SN-M300
    Power Tolerance
    ±3 %
    Maximum Power(Pmax)
    300Wp
    Maximum Series Fuse Rating
    15A
    Optimum Operating Voltage/Vmp
    36.0V
    Maximum System Voltage
    1000V DC
    Optimum Operating Current/Imp
    8.33A
    Operating Module Temperature
    -40°C to +80°C
    Open Circuit Voltage /Voc
    43.2V
    Frame Material
    Clear Anodized aluminum Frame
    Short Circuit Current /Isc
    9.13A
    Thickness of glass
    3.2mm tempered glass
    Module Efficiency
    15.54%
    Frame
    Anodized aluminum alloy
    Weight
    22Kg
    Laminating material
    EVA
    Numbers of cells
    72(6*12)
    Backsheet material
    TPT
    Cell dimension
    156*156mm
    Junction box
    Ip65
    Dimensions(mm)
    1950*990*40mm
    Standard test condition
    Irradiance 1000W/m²,Module temperature 25℃, AM=1.5
    Product Detail Show

    GLASS

    > Antireflective glass
    > Translucency of normal luminance is increased by 2%
    > Module efficiency is increased by 2%
    > Self-cleaning function
    > Service life is as long as 25 years(30 years optional)

    Waterproof 310W 36V Monocrystalline Solar Panel , Thin Solar Panels With White Aluminum

    FRAME

    > Conventional frame
    > Silver or black frames are optional
    > Boost bearing capability and prolong service life
    > Serra-clip design tensile strength
    > Seal-lip designglue injection

    Waterproof 310W 36V Monocrystalline Solar Panel , Thin Solar Panels With White Aluminum

    SOLAR CELL

    > High Efficiency PV Cells
    > Appearance Consistency
    > Color sorting ensure consistent appearance on each module
    > Anti-PID

    Waterproof 310W 36V Monocrystalline Solar Panel , Thin Solar Panels With White Aluminum

    JUNCTION BOX

    > Conventional standalone edition and engineering custom edition
    > Quality diode ensures module running safety
    > IP65 Protection level
    > Heat dissipation
    > Long service life

    ▶ Customized size, voltage,

    power and shape
    ▶ 24 hours online
    ▶ Delivery on time, 15-20 days lead timefor glass solar panels,
    ▶ Can provide specialized guidance to customers
    ▶As long as send an order to our company ,you will always be our VIP customer
